Negele EM Pressure Gauge With 90 mm Display

Mechanical 90mm pressure gauge for hygienic pressure measurement in pipes/vessels for pharmaceutical industry

Autoclaveable version with CPM or Tri-Clamp 1,5? process connectionAdjustment of zero and spanProduct contact surfaces electropolished, Ra < = 0,2 ?mLong-life technology with wear-free mechanical systemMultiple diaphragm protection for extended lifetime, optionally with setback position to avoid damageAdjustment of zero and span at any momentExcellent visibility due to big display sizeIncl. material certificates

Further information:

The gauge EM replaces the MAN-90P series. A special feature is the recessed diaphragm, that protects the diaphragm from mechanical damage, for example during transport or re-calibration.

Technical SpecificationProcess ConnectionTri-Clamp | CPM | VariventWetted materialStainless steel 1.4404 (316L) Ra?0,2 ?m (electropolished) | Option 1.4435, Ra?0,2 ?m (electropolished) | Option HastelloyMeasuring range-1…20 bar Relative | 0…40 bar RelativeAccuracy±0.75% of end valueTemperature range process-29…165 °CTemperature range CIP/SIP149 °C continuousCommunicationDisplay without external power supply
